Structural and microvascular changes in the retina and choroid in patients with chronic kidney disease

Close metadata

PURPOSE

To study the main structural and microvascular changes in the retina and choroid in patients with diabetic retinopathy (DR) and chronic kidney disease (CKD), and their relationship with impaired renal function.

MATERIAL AND METHODS

The study included 158 patients (304 eyes). The 1^st group consisted of 50 patients with CKD (97 eyes); group 2 — 65 patients with DR (119 eyes), group 3 — 43 patients with CKD and DR (86 eyes). All study patients underwent complete ophthalmological examination, including optical coherence tomography (OCT) and OCT angiography (OCTA) of the macular region.

RESULTS

The analysis of structural parameters in groups of patients showed a decrease in the thickness of the ganglion cell layer and the inner plexiform layer of the retina in patients with DR (70.85±14.49 μm), with the lowest value in the CKD+DR group (65.84±15.34 μm) in comparison with the CKD group (75.64±10.32 μm). In the groups of patients with CKD, the thickness of the choroid (207.3±40.36 μm) was significantly reduced in comparison with the group of patients with DR (258.8±26.63 μm) and correlated with the stage of the disease. Patients in the CKD+DR group had the lowest perfusion and vascular density in the macular region (31.23±10.91% and 13.15±2.73 mm), an increase in the area and perimeter of the foveal avascular zone (0.55±0.26 mm², 3.30±0.84 mm). Pronounced correlations of decrease in choroidal thickness, vascular density, and perfusion volume with low glomerular filtration rate and CKD stage, as well as urea and creatinine levels were determined. An increase in the area of the foveal avascular zone correlated with lower retinal capillary density, decreased perfusion volume, and the stage of both DR and CKD.

CONCLUSION

Structural and hemodynamic disorders of the retina and choroid can be recognized as significant biomarkers for non-invasive diagnosis of microvascular complications of diabetes mellitus and impaired renal function.

Keywords:

diabetic retinopathy

chronic kidney disease

OCT

OCT angiography

vascular density

perfusion density

ganglion cells

foveolar avascular zone

Authors:

Fursova A.Zh.

Novosibirsk State Regional Clinical Hospital;
Novosibirsk State Medical University

Derbeneva A.S.

Novosibirsk State Regional Clinical Hospital;
Novosibirsk State Medical University

Vasilyeva M.A.

Novosibirsk State Regional Clinical Hospital

Tarasov M.S.

Novosibirsk State Regional Clinical Hospital;
Novosibirsk State Medical University

Nikulich I.F.

Novosibirsk State Regional Clinical Hospital;
Novosibirsk State Medical University

Gamza Yu.A.

Novosibirsk State Medical University;
Private Healthcare institution Clinical Hospital «RZD-Medicine» Novosibirsk

Received:

29.08.2021

Accepted:

31.10.2021

List of references:

Dronavalli S, Duka I, Bakris GL. The pathogenesis of diabetic nephropathy. Nat Clin Pract Endocrinol Metab. 2008;4(8):444-452. https://doi.org/10.1038/ncpendmet0894
Khachaturian NE. Chronic renal disease in patients with type 2 diabetes mellitus. Cardiosomatics = Kardiosomatika. 2019;10(2):65-70 (In Russ.). https://doi.org/10.26442/22217185.2019.2.190317
Leehey DJ, Kramer HJ, Daoud TM, et al. Progression of kidney disease in type 2 diabetes — Beyond blood pressure control: An observational study. BMC Nephrol. 2005;6:8. https://doi.org/10.1186/1471-2369-6-8
Zhuang X, Cao D, Zeng Y, et al. Associations between retinal microvasculature/ microstructure and renal function in type 2 diabetes patients with early chronic kidney disease. Diabetes Res Clin Pract. 2020;168:108373. https://doi.org/10.1016/j.diabres.2020.108373
Edwards MS, Wilson DB, Craven TE, et al. Associations between retinal microvascular abnormalities and declining renal function in the elderly population: The Cardiovascular Health Study. Am J Kidney Dis. 2005;46(2):214-224. https://doi.org/10.1053/j.ajkd.2005.05.005
Kashani AH, Chen CL, Gahm JK, et al. Optical coherence tomography angiography: A comprehensive review of current methods and clinical applications. Progress Retinal Eye Res. 2017;60:66-100. https://doi.org/10.1016/j.preteyeres.2017.07.002
Nagaoka T, Yoshida A. Relationship between retinal blood flow and renal function in patients with type 2 diabetes and chronic kidney disease. Diabetes Care. 2013;36(4):957-961. https://doi.org/10.2337/dc12-0864
Budzinskaya MV, Lipatov DV, Pavlov VG, Petrachkov DV. Biomarkers for diabetic retinopathy. Diabetes Mellitus = Sakharnyy diabet. 2020;23(1):88-94. (In Russ.). https://doi.org/10.14341/DM10045
Nickla DL, Wallman J. The multifunctional choroid. Prog Retin Eye Res. 2010;29(2):144-168. https://doi.org/10.1016/j.preteyeres.2009.12.002
Fletcher EL, Phipps JA, Ward MM. The renin-angiotensin system in retinal health and disease: its influence on neurons, glia and the vasculature. Prog Retin Eye Res. 2010;29(4):284-311. https://doi.org/10.1016/j.preteyeres. 2010.03.003
Mauer M, Zinman B, Gardiner R. Renal and retinal effects of enalapril and losartan in type 1 diabetes. N Engl J Med. 2009;361(1):40-51. https://doi.org/10.1056/NEJMoa0808400
Mulè G, Vadalà M, La Blasca T. Association between early-stage chronic kidney disease and reduced choroidal thickness in essential hypertensive patients. Hypertens Res. 2019;42(7):990-1000. https://doi.org/10.1038/s41440-018-0195-1
Shin YU, Lee DE, Kang MH, et al. Optical coherence tomography angiography analysis of changes in the retina and the choroid after haemodialysis. Sci Rep. 2018;8(1):17184. https://doi.org/10.1038/s41598-018-35562-6
Weinberger D, Kramer M, Priel E, et al. Indocyanine green angiographic findings in nonproliferative diabetic retinopathy. Am J Ophthalmol. 1998; 126(2):238-247. https://doi.org/10.1016/s0002-9394(98)00148-2
Dumskyj MJ, Eriksen JE, Doré CJ, Kohner EM. Autoregulation in the human retinal circulation: assessment using isometric exercise, laser Doppler velocimetry, and computer-assisted image analysis. Microvasc Res. 1996;51(3): 378-392. https://doi.org/10.1006/mvre.1996.0034
Robinson F, Riva CE, Grunwald JE, et al. Retinal blood flow autoregulation in response to an acute increase in blood pressure. Invest Ophthalmol Vis Sci. 1986;27(5):722-726.
Zhang Y, Weng H, Li Q, Wang Z. Changes in retina and choroid after haemodialysis assessed using optical coherence tomography angiography. Clin Exp Optom. 2018;101(5):674-679. https://doi.org/10.1111/cxo.12660
Van Dijk HW, Verbraak FD, Kok PH. Early neurodegeneration in the retina of type 2 diabetic patients. Invest Ophthalmol Vis Sci. 2012;53(6):2715-2719. https://doi.org/10.1167/iovs.11-8997
De Clerck EE, Schouten JS, Berendschot TT. New ophthalmologic imaging techniques for detection and monitoring of neurodegenerative changes in diabetes: a systematic review. Lancet Diabetes Endocrinol. 2015;3(8):653-663. https://doi.org/10.1016/S2213-8587(15)00136-9
Kim K, Kim ES, Yu SY. Optical coherence tomography angiography analysis of foveal microvascular changes and inner retinal layer thinning in patients with diabetes. Br J Ophthalmol. 2018;102(9):1226-1231. https://doi.org/10.1136/bjophthalmol-2017-311149
Sohn EH, van Dijk HW, Jiao C. Retinal neurodegeneration may precede microvascular changes characteristic of diabetic retinopathy in diabetes mellitus. Proc Natl Acad Sci USA. 2016;113(19):2655-2664. https://doi.org/10.1073/pnas.1522014113
Sun Z, Tang F, Wong R. OCT angiography metrics predict progression of diabetic retinopathy and development of diabetic macular edema: a prospective study. Ophthalmology. 2019;126(12):1675-1684. https://doi.org/10.1016/j.ophtha.2019.06.016
Fursova AZh, Vasilyeva MA, Derbeneva AS, Tarasov MS, Chubar NV, Nikulich IF, Gusarevitch OG. Optical coherence tomography angiography in the diagnosis of retinal microvascular changes in chronic kidney disease (clinical observations). Vestnik oftal’mologii. 2021;137(3):97-104. https://doi.org/10.17116/oftalma202113703197
Fursova AZh, Derbeneva AS, Vasilyeva MA, Tarasov MS, Nikulich IF, Galkina EV. Development, clinical manifestations and diagnosis of retinal changes in chronic kidney disease. Vestnik Ooftal’mologii. 2021;137(1):107-114. https://doi.org/10.17116/oftalma2021137011107
Lim LS, Cheung CY, Sabanayagam C, et al. Structural changes in the retinal microvasculature and renal function. Invest Ophthalmol Vis Sci. 2013; 54(4):2970-2976. https://doi.org/10.1167/iovs.13-11941
Ooi QL, Tow FK, Deva R, et al. The microvasculature in chronic kidney disease. Clin J Am Soc Nephrol. 2011;6(8):1872-1878. https://doi.org/10.2215/CJN.10291110
Vadala M, Castellucci M, Guarrasi G. Retinal and choroidal vasculature changes associated with chronic kidney disease. Graefes Arch Clin Exp Ophthalmol. 2019;257(8):1687-1698. https://doi.org/10.1007/s00417-019-04358-3
Yeung L, Wu IW, Sun CC, et al. Early retinal microvascular abnormalities in patients with chronic kidney disease. Microcirculation. 2019;26(7):e12555. https://doi.org/10.1111/micc.12555
Johannesen SK, Viken JN, Vergmann AS, Grauslund J. Optical coherence tomography angiography and microvascular changes in diabetic retinopathy: a systematic review. Acta Ophthalmol. 2019;97(1):7-14. https://doi.org/10.1111/aos
