Distraction enterogenesis: effectiveness of experimental devices and clinical prospects

Ryabkov M.G.; Koshmanyov M.S.; Rotkov A.I.; Kiseleva E.B.

doi:https://doi.org/10.17116/medtech202547031103

Abstract:

OBJECTIVE

To identify perspective devices for distraction enterogenesis (DE) through analysis of their design, efficiency and complications.

MATERIAL AND METHODS

The PubMed, Google Scholar and eLibrary databases were screened regarding data on devices for experimental DE. Analysis included 25 articles. Devices were classified as intraluminal and extraluminal, controlled (retrievable) and uncontrolled.

RESULTS

Intraluminal uncontrolled devices increase intestinal length by 176% [114; 243] with the highest risk of abdominal complications. Intraluminal controlled devices are characterized by intestinal length increase by 69% [45; 80] with small risk of complications. Extraluminal devices provide a 100% increase in intestinal length in both controlled and uncontrolled versions.

CONCLUSION

Optimal balance of effectiveness and safety required for clinical implementation of distraction enterogenesis method is typical for devices with possible rapid atraumatic removal regardless of localization relative to intestinal lumen.

Keywords:

distraction enterogenesis

device for distraction enterogenesis

Authors:

Ryabkov M.G.

Privolzhsky Research Medical University

ORCID: 0000-0002-9555-190X

Koshmanyov M.S.

Privolzhsky Research Medical University

ORCID: 0000-0002-4171-0063

Rotkov A.I.

Privolzhsky Research Medical University

ORCID: 0000-0002-6678-8422

Kiseleva E.B.

Privolzhsky Research Medical University

ORCID: 0000-0003-4769-417X

Received:

17.07.2024

Accepted:

15.11.2024

Close metadata

References:

Koga H, Sun X, Yang H, Nose K, Somara S, Bitar KN, et al. Distraction-induced intestinal enterogenesis: preservation of intestinal function and lengthening after reimplantation into normal jejunum. Annals of Surgery. 2012;255(2):302-310. https://doi.org/10.1097/SLA.0b013e318233097c
Pironi L. Definitions of intestinal failure and the short bowel syndrome. Best Practice and Research. Clinical Gastroenterology. 2016;30(2):173-185. https://doi.org/10.1016/j.bpg.2016.02.011
Wales PW, Allen N, Worthington P, George D, Compher C, American Society for Parenteral and Enteral Nutrition, Teitelbaum DA.SP.EN. clinical guidelines: support of pediatric patients with intestinal failure at risk of parenteral nutrition-associated liver disease. JPEN. Journal of Parenteral and Enteral Nutrition. 2014;38(5):538-557. https://doi.org/10.1177/0148607114527772
Rosinov MV, Chubarova AI, Erpuleva YuV, Averianova YuV, Demura SA, Kosov DA. Russian register of children with short bowel syndrome. Rossijskij vestnik detskoj khirurgii, anesteziologii i reanimatologii. 2017;7(4):38-45. (In Russ.).
Abi Nader E, Lambe C, Talbotec C, Pigneur B, Lacaille F, Garnier-Lengliné H, et al. Outcome of home parenteral nutrition in 251 children over a 14-y period: report of a single center. The American Journal of Clinical Nutrition. 2016;103(5):1327-1336. https://doi.org/10.3945/ajcn.115.121756
Gautier SV, Khomyakov SM. Organ donation and transplantation in the Russian Federation in 2023. 16th Report from the Registry of the Russian Transplant Society. Vestnik transplantologii i iskusstvenny`x organov. 2024;26(3):8-31. (In Russ.). https://doi.org/10.15825/1995-1191-2024-3-8-31
Neumann CG. The expansion of an area of skin by progressive distention of a subcutaneous balloon; use of the method for securing skin for subtotal reconstruction of the ear. Plastic and Reconstructive Surgery (1946). 1957;19(2):124-130. https://doi.org/10.1097/00006534-195702000-00004
Huynh N, Dubrovsky G, Rouch JD, Scott A, Chiang E, Nguyen T, et al. Three-dimensionally printed surface features to anchor endoluminal spring for distraction enterogenesis. PLoS One. 2018;13(7):e0200529. https://doi.org/10.1371/journal.pone.0200529
Stark GB, Dorer A, Walgenbach KJ, Grünwald F, Jaeger K. The creation of a small bowel pouch by tissue expansion--an experimental study in pigs. Langenbecks Archiv fur Chirurgie. 1990;375(3):145-150. https://doi.org/10.1007/BF00206807
Averyanova YuV, Razumovsky AYu, Makarov SP, Petrov DA, Brusov GP, Kochkin VS, et al. Current strategy for management of short bowel syndrome: a twelve-year single-center experience. Russian Journal of Anesthesiology and Reanimatology. 2018;(6):67-74. (In Russ.). https://doi.org/10.17116/anaesthesiology201806167
Petrov DA, Averyanova YuV, Trofimchuk ES, Tsinzerling VA, Sedush NG, Krupnin AE, et al. Synchronous lengthening of several segments of the small intestine using biodegradable springs in an experiment. Klinicheskaya i e`ksperimental`naya xirurgiya. 2020;8(4):16-28. (In Russ.). https://doi.org/10.33029/2308-1198-2020-8-4-16-28
Demehri FR, Utter B, Freeman JJ, Fukatsu Yu, Luntz J, Brei D, et al. Development of an endoluminal intestinal attachment for a clinically applicable distraction enterogenesis device. Journal of Pediatric Surgery. 2016;51(1):101-106. https://doi.org/10.1016/j.jpedsurg.2015.10.026
Dubrovsky G, Huynh N, Thomas AL, Shekherdimian S, Dunn JC. Double plication for spring-mediated in-continuity intestinal lengthening in a porcine model. Surgery. 2019;165(2):389-392. https://doi.org/10.1016/j.surg.2018.07.028
Hosseini HS, Wood LSY, Taylor JS, Dubrovsky G, Portelli KI, Anne-Thomas L, et al. Biomechanical signaling and collagen fiber reorientation during distraction enterogenesis. Journal of the Mechanical Behavior of Biomedical Materials. 2020;101:103425. https://doi.org/10.1016/j.jmbbm.2019.103425
Rafeeqi TA, Thomas AL, Salimi-Jazi F, Diyaolu M, Dunn JCY. Internal plication for spring confinement to lengthen intestine in a porcine model. PLoS One. 2022;17(9):e0274612. https://doi.org/10.1371/journal.pone.0274612
Sullins VF, Scott A, Wagner JP, Steinberger D, Lee SL, Wu BM, et al. Intestinal lengthening in an innovative rodent surgical model. Journal of Pediatric Surgery. 2014;49(12):1791-1794. https://doi.org/10.1016/j.jpedsurg.2014.09.022
Demehri FR, Stephens L, Herrman E, West B, Mehringer A, Arnold MA, et al. Enteral autonomy in pediatric short bowel syndrome: predictive factors one year after diagnosis. Journal of Pediatric Surgery. 2015;50(1):131-135. https://doi.org/10.1016/j.jpedsurg.2014.10.011
Demehri FR, Wong PM, Freeman JJ, Fukatsu Y, Teitelbaum DH. A novel double-balloon catheter device for fully endoluminal intestinal lengthening. Pediatric Surgery International. 2014;30(12):1223-1229. https://doi.org/10.1007/s00383-014-3612-9
Anderson T, Mueller C, Dunn J. Intestinal lengthening via mechanical enterogenesis in an infant with short gut syndrome. Journal of Pediatric Surgery Case Reports. 2023;91:102594. https://doi.org/10.1016/j.epsc.2023.102594
Luntz J, Brei D, Teitelbaum D, Spencer A. Mechanical extension implants for short-bowel syndrome. Proceedings of SPIE — the International Society for Optical Engineering. 2006;6173:617309. https://doi.org/10.1117/12.659112
Spencer AU, Sun X, El-Sawaf M, Haxhija EQ, Brei D, Luntz J, et al. Enterogenesis in a clinically feasible model of mechanical small-bowel lengthening. Surgery. 2006;140(2):212-220. https://doi.org/10.1016/j.surg.2006.03.005
Diyaolu M, Thomas AL, Wood LS, Taylor J, Dunn JC. Mesenteric neovascularization during spring-mediated intestinal lengthening. Journal of Pediatric Surgery. 2021;56(1):5-10. https://doi.org/10.1016/j.jpedsurg.2020.09.042
Dubrovsky G, Taylor JS, Thomas AL, Shekherdimian S, Dunn JCY. Optimization of in-continuity spring-mediated intestinal lengthening. Journal of Pediatric Surgery. 2020;55(1):158-163. https://doi.org/10.1016/j.jpedsurg.2019.09.072
Dubrovsky G, Huynh N, Thomas AL, Shekherdimian S, Dunn JC. Intestinal lengthening via multiple in-continuity springs. Journal of Pediatric Surgery. 2019;54(1):39-43. https://doi.org/10.1016/j.jpedsurg.2018.10.036
Portelli KI, Park JB, Taylor JS, Thomas A-L, Stelzner M, Martin MG, et al. Intestinal adaptation following spring insertion into a roux limb in mice. Journal of Pediatric Surgery. 2021;56(2):346-351. https://doi.org/10.1016/j.jpedsurg.2020.06.033
Rafeeqi TA, Diyaolu M, Thomas AL, Salimi-Jazi F, Wood LSY, Dunn JCY. Generation of Porcine Ileum Through Spring-Mediated Mechanical Distraction. The Journal of Surgical Research. 2022;280:371-378. https://doi.org/10.1016/j.jss.2022.07.043
Shekherdimian S, Panduranga MK, Carman GP, Dunn JC. The feasibility of using an endoluminal device for intestinal lengthening. Journal of Pediatric Surgery. 2010;45(8):1575-1580. https://doi.org/10.1016/j.jpedsurg.2010.03.015
Stark R, Panduranga M, Carman G, Dunn JC. Development of an endoluminal intestinal lengthening capsule. Journal of Pediatric Surgery. 2012;47(1):136-141. https://doi.org/10.1016/j.jpedsurg.2011.10.031
Wood LS, Hosseini HS, Diyaolu M, Thomas AL, Taylor JS, Dunn JC. Mechanical lengthening of porcine small intestine with decreased forces. Journal of Pediatric Surgery. 2021;56(7):1192-1198. https://doi.org/10.1016/j.jpedsurg.2021.03.036
Hausbrandt PA, Ainoedhofer H, Saxena AK, Schalamon J. Mechanical elongation of the small intestine: evaluation of techniques for optimal screw placement in a rodent model. BioMed Research International. 2013;2013:601701. https://doi.org/10.1155/2013/601701
Park J, Puapong DP, Wu BM, Atkinson JB, Dunn JC. Enterogenesis by mechanical lengthening: morphology and function of the lengthened small intestine. Journal of Pediatric Surgery. 2004;39(12):1823-1827. https://doi.org/10.1016/j.jpedsurg.2004.08.022
Huynh N, Rouch JD, Scott A, Chiang E, Wu BM, Shekherdimian S, Dunn JC. Spring-mediated distraction enterogenesis in-continuity. Journal of Pediatric Surgery. 2016;51(12):1983-1987. https://doi.org/10.1016/j.jpedsurg.2016.09.024
Sullins VF, Wagner JP, Suwarnasarn AT, Lee SL, Wu BM, Dunn JC. A novel biodegradable device for intestinal lengthening. Journal of Pediatric Surgery. 2014;49(1):109-113. https://doi.org/10.1016/j.jpedsurg.2013.09.040
Thompson JS, Pinch LW, Young R, Vanderhoof JA. Long-term outcome of intestinal lengthening. Transplantation Proceedings. 2000;32(6):1242-1243. https://doi.org/10.1016/s0041-1345(00)01207-0
Wu G, Jiang Y, Zhu X, Jin D, Han Y, Han J, et al. Prevalence and risk factors for complications in adult patients with short bowel syndrome receiving long-term home parenteral nutrition. Asia Pacific Journal of Clinical Nutrition. 2017;26(4):591-597. https://doi.org/10.6133/apjcn.082016.08
Coletta R, Olivieri C, Persano G, Solari V, Inserra A, Morabito A. Expanding intestinal segment using osmotic hydrogel: An in vivo study. Journal of Biomedical Materials Research. Part B, Applied Biomaterials. 2019;107(4):1304-1309. https://doi.org/10.1002/jbm.b.34224
Demehri FR, Freeman JJ, Fukatsu Y, Luntz J, Teitelbaum DH. Development of an endoluminal intestinal lengthening device using a geometric intestinal attachment approach. Surgery. 2015;158(3):802-811. https://doi.org/10.1016/j.surg.2015.03.055
Printz H, Schlenzka R, Requadt P, Tscherny M, Wagner AC, Eissele R, et al. Small bowel lengthening by mechanical distraction. Digestion. 1997;58(3):240-248. https://doi.org/10.1159/000201450
Fisher JG, Sparks EA, Khan FA, Dionigi B, Wu H, Brazzo J 3rd, et al. Extraluminal distraction enterogenesis using shape-memory polymer. Journal of Pediatric Surgery. 2015;50(6):938-942. https://doi.org/10.1016/j.jpedsurg.2015.03.013
Dionigi B, Brazzo J 3rd, Connors JP, Ahmed A, Fisher JG, Zurakowski D, et al. Extraluminal helicoidal stretch: a novel method of intestinal lengthening. Journal of Pediatric Surgery.2014;49(12):1787-1790. https://doi.org/10.1016/j.jpedsurg.2014.09.020
